- Transform
any existing powerline into a robust, high-speed DMX and Pixel data
network. Built for professionals, managed from the Cloud.
- Securely
manage your entire network of Master and Slave nodes from anywhere. Push
OTA updates, monitor real-time environmentals, and configure DMX universes
wirelessly.
- Utilizing
industry-standard G3-PLC modulation, PowerDMX punches through electrical
noise to deliver pixel-perfect sACN and DDP data over standard AC/DC
wiring.
- Ditch
the laptop. Trigger stunning built-in pixel effects or stream massive
ZLIB-compressed xLights .fseq files directly from the onboard SD card.
- DMX
Receiver and Controller, inc RDM discovery
- Works
with industry standards like E1.31 sACN, DDP (Distributed Display
Protocol), MQTT, WIFI, DMX (Opto-Isolated) and PLC (Power-Line Control)
- Drives
clock-less addressable pixels (like WS2811), traditional DMX512 devices, and
PWM outputs (4 x Analog Channels (R,G,B,W) or 7 x PIXEL channels (each to
1024 pixels))
- Discovery
via WIFI or PLC
- Built
in Effects for sequences, or runs a FQ
- Supports
standalone playback or FPP (Falcon Player) Remote multi-sync mode using
stored sequence files on compatible SD card
- Can be
a Master of Nodes, or independent slave
- Ethernet
10/100 option, and USB-C control.
- Supply
voltage: 12-24VAC, Internal Power supply to convert AC to DC up to 6A
- Housekeeping
inc Logging on Temp and voltages
- LCD
display for local setup and control, also HTTPS over MQTT for Web Control
- Remote
OTA code updates, inc Slave nodes
- Working
temperature: -20+40 °C
- 1 year
warranty
| Voltage / Power | |
| Input Voltage | 12-24 VAC |
| Wattage | 5-100W |
| General | |
| IP Rated | No |
| Cable Included | No |
| Location | Indoor |
| Profile | Rectangle |
| Material | Plastic |
| Dimensions | |
| Length | 4" |
| Width | 4" |
| Height | 2" |
| Warranty | |
| 1 yr. | |
