  • LED 30 degree sealed-beam Spotlight PAR36 5W, 10-30V AC/DC, Equivalent to 35-50W Halogen with 85% Energy saving, i.e replacement for GE 4445, & 4454  (For 120 degree floodlight, see EV-LED-PAR36-9W)
  • Suitable for off-road vehicles (Quad Bike, lawn mower, tractor, motorbike & skidoo) also Landscape Well Light for narrow beam up-light of architectural pillar or tall tree.
  • Custom LED Driver circuit to withstand voltage surges in Landscape environments
  • 2 colors available, 3000K Warm-White (Landscape), or 6000K (Auto) Cool White. Luminous flux: 600-680LM, 30 degree spread
  • Protect level: IP65 (Splash / Waterjet proof) – avoid pooling water
  • No UV or IR radiation, low heat
  • Base: Screw Terminal
  • Size: Dia 112 * 60mm (exact same as standard glass Halogen PAR36)
  • Light source: 18 x Epistar SMT 2835 LED
  • Life: 50,000 hours, min 70% of initial output.
  • 2 year warranty
  • Ensure that the lamp is installed above ground level, within a fixture, and for landscape use, with drainage (stone chips) below the lamp to avoid pooling from flash downpours. Product not warranted for Water damage.
Bulb Type
PAR36
Voltage / Power
Input Voltage 10-24V AC/DC
Wattage 8W
General
Lumens 680
Bulb Included Yes
LED Qty 18
Dimmable No
IP Rated IP65 No Dust / Water Jets
submersible No
Cable Included No
Wiring (Series / Parallel) Parallel
Location Outdoor
Material Glass
Angle 30
Dimensions
Height 2.36"
Diameter 4.45"
Warranty
1 yr.
