File Size
Datasheet 303.66KB Download
  • LED PAR36 5W, 10-30V AC/DC, Well Lamp, Eq to 35W Halogen with 85% Energy saving
  • Suitable for Landscape Well Light replacement.  Custom LED Driver circuit to withstand voltage surges in Landscape environments
  • Luminous flux: 450-500LM, 120 degree spread, Replace 36PAR36, 19877, 55091, 42072, 55057, 55091
  • Color temperature: 3000K, Warm-white, CRI > 73Ra
  • Protect level: IP65 (Splash / Waterjet proof)
  • No UV or IR radiation, low heat
  • Base: Screw Terminal
  • Size: Dia 113 * 60mm
  • Light source: 30 x SMT 2835 LED
  • Life: 35,000 hours, min 70% of initial output.
  • 2 year warranty
  • Ensure that the lamp is installed above ground level, within a fixture, with drainage (stone chips) below the lamp to avoid pooling from flash downpours.  Product not warranted for Water damage.
Bulb Type
PAR36
Voltage / Power
Input Voltage 10-24V AC/DC
Wattage 5W
General
Lumens 500
Bulb Color Warm White
Bulb Included Yes
Color Temperature K 3000K
LED Qty 30
Dimmable Yes
IP Rated IP65 No Dust / Water Jets
submersible No
Cable Included No
Wiring (Series / Parallel) Parallel
Location Outdoor
Material Glass
Angle 120
Dimensions
Height 2.36"
Diameter 4.45"
Warranty
1 yr.
Life (hrs) 30000

Write a review

Please login or register to review

LED 5W (Eq. to 35W) PAR36 12V AV/DC Flood Lamp LED

  • Brand: illuminous
  • Product Code: EV-LED-PAR36-5W
  • Availability: In Stock
MRP: $9.49 $2.0021% OFF
  • $7.49

Buy 20 for $7.27 each and save 3.00%
Buy 50 for $7.12 each and save 5.00%
Buy 100 for $6.97 each and save 7.00%
Buy 200 for $6.89 each and save 8.00%
