Perfect to replace 15W Halogen G4 Capsules, Automotive, RV, Boats, Spots & Pendants, Appliances, with a Silicon cover making them waterproof IP65, perfect for landscaping
Color: Warm White 3000K, 170 Lumens +-10%
No UV or IR radiation, low heat, highly efficient operation and low operating costs
Base: G4, enables fitting in any G4 luminaries
Input: 12V AC/DC, Power: 1.7W
Size: Φ12.6 x H28 mm (Φ0.5" x 1.10") (not including 10mm Pin Length)
Light source: 48 x 3014 LED, 360 degree Viewing Angle
An exceptionally long lamp life of up to 50,000 hours makes lamps ideal for inaccessible locations
Color temperature: 2800-3000K, Warm-white, CRI > 73Ra
Protect level: IP65 (Splash / Waterjet proof)
No UV or IR radiation, low heat
Base: Crew Terminal
Size: Dia 113 * 60mm
Light source: 60 x SMT 2835 LED
Life: 35,000 hours, min 70% of initial output.
2 year warranty
Ensure that the lamp is installed above ground level, within a fixture, with drainage (stone chips) below the lamp to avoid pooling from flash downpours. Product not warranted for Water damage.
For 40W see EV-LED-GY635-4W, for 75W see EV-LED-GY635-8W
Color: Warm White 3000K, 540 Lumens +110%, 49 x 5050LED, CRI > 80
No UV or IR radiation, low heat, highly efficient operation and low operating costs
Base: GY6.35, enables fitting in any GY6.35 luminaries
Input: DC10-30V & AC8-18V
Size: Φ25.0 x 34.8 H mm (0.98" Φ x 1.37" H) (45.24mm 1.78” inc pins)
An exceptionally long lamp life of up to 50,000 hours makes lamps ideal for inaccessible locations
Working Temperature -35C to +55C
2 year warranty
Note: if replacing a 35W to 50W Halogen for this 6W LED, you may see flicker which is indicative of a problem with your transformer which can no longer regulate with a load now only 15% of the original, hence you may have to replace the transformer for a smaller LED Driver, i.e say 12W LED driver (i.e EV-12V-1000-12D) to replace a 100W transformer.
10m length, 100 led, 110V, Linkable, IP67 outdoor use
Color: Warm White 3000K, 5mm, 25 LM, Wide-Angle LED
Green color Wire, UL1015, 22AWG gauge AWG, 2.8mm, PVC, Copper wire
Linkable: waterproof male/female connectors at each end, Daisy-chain up to 5 lengths.
Dongle: (Not Included) USA plug 2 pin, 0.5m L, 2.5A 125V (No Transformer). MUST be wired to GFCI socket.
Working temperature: less than -10 to 40°C, can be used continuously in cold weather.
Individual LED, if one fails, the rest remain lit. Fixed LED, so rapid install, do not need to check each LED is inserted.
Size: 10M length
Life: 30,000 hours, min 70% of initial output.
1 year warranty
Example: we have a 4'H trunk that measures 2' in circumference, and we plan to wrap four of the stronger branches, which measure 3'L and 6" in circumference. Use this equation to learn how to wrap a tree with lights:
4'H trunk / 3" spacing = 16 x 2' circumference = 32' of lighting
3'L branch / 3" spacing = 12 x 6" circumference = 6' of lighting per branch
Total lighted feet will be approximately 56' for the trunk and four branches
1 dongle can do 2-5 strings. So 1 string = 10m = 33ft, so 2 lengths per tree is enough (2x33=66ft) - depending how you wrap the tree, and spacing…
8W (Equivalent to 60-75W Halogen) LED GY6.35 12V AC/DC Lamp Bulb
Perfect to replace Halogen GY6.35 Capsules, RV, Marine, Spots & Pendants, Appliances (Check the Physical Space)
For 40W see EV-LED-GY635-4W, for 50W see EV-LED-GY635-6W
Color: Warm White 3000K, 800 Lumens, 66 x 5050LED, CRI > 80
No UV or IR radiation, low heat, highly efficient operation and low operating costs
Base: GY6.35, enables fitting in any GY6.35 luminaries
Input: DC10-30V & AC8-18V
Size: Φ26.5 x 62.0mm H(1.04" Φ x 2.44" H) (72mm 2.83” inc pins)
An exceptionally long lamp life of up to 50,000 hours makes lamps ideal for inaccessible locations
Working Temperature -35C to +55C
2 year warranty
Note: if replacing a 50W to 75W Halogen for this 8W LED, you may see flicker which is indicative of a problem with your transformer which can no longer regulate with a load now only 15% of the original, hence you may have to replace the transformer for a smaller LED Driver, i.e say 12W LED driver (i.e EV-12V-1000-12D) to replace a 100W transformer.
For 50W see EV-LED-GY635-6W, for 75W see EV-LED-GY635-8W
Color: Warm White 3000K, 420 Lumens +-10%, 36 x 5050LED, CRI > 80
No UV or IR radiation, low heat, highly efficient operation and low operating costs
Base: GY6.35, enables fitting in any GY6.35 luminaries
Input: DC10-30V & AC8-18V
Size: Φ19.5.0 x 35.7 H mm (0.77" Φ x 1.4" H) (45.1mm 1.78” inc pins)
An exceptionally long lamp life of up to 50,000 hours makes lamps ideal for inaccessible locations
Working Temperature 0C to +55C
2 year warranty
Note: if replacing a 35W to 50W Halogen for this 4W LED, you may see flicker which is indicative of a problem with your transformer which can no longer regulate with a load now only 15% of the original, hence you may have to replace the transformer for a smaller LED Driver, i.e say 12W LED driver (i.e EV-12V-1000-12D) to replace a 100W transformer.
Color temperature: 2800-3000K, Warm-white, CRI > 73Ra
Protect level: IP65 (Splash / Waterjet proof)
No UV or IR radiation, low heat
Base: Crew Terminal
Size: Dia 113 * 60mm
Light source: 60 x SMT 2835 LED
Life: 35,000 hours, min 70% of initial output.
2 year warranty
Ensure that the lamp is installed above ground level, within a fixture, with drainage (stone chips) below the lamp to avoid pooling from flash downpours. Product not warranted for Water damage.
Ensure that the lamp is installed above ground level, within a fixture, with drainage (stone chips) below the lamp to avoid pooling from flash downpours. Product not warranted for Water damage.
BA15S base for Dash Indicator Light, Corner Light, Side Marker Light
35 x Longer life time compared with traditional Incandescent bulbs, plus less heat output and extremely low power consumption
Direct replacement for BA15S base, single filament, Trade Number 97, Lamp Shape G6, 1156 Series also known as: 93, 3497, 1073, 1141, 1159, 1295, 7527 12814, 1003 (For Reference Only)
No UV or IR radiation, low heat
Base: BA15S, diameter 0.59” (15mm)
Size: Total length 1.45” (36.85mm, Max Diameter 0.748” (19mm)
Luminous flux: 119LM, Color temperature: 2800-3200K
Input: 12V, Built-in Circuit for 12V DC Voltage Input
You must remove the ballast, and wire 12V direct to the Tube connector (see instructions). If you need 110V, to convert the Ballast to LED Driver, order a EV-12V-2200-33D LED Driver.
BA15S base for Dash Indicator Light, Corner Light, Side Marker Light
35 x Longer life time compared with traditional Incandescent bulbs, plus less heat output and extremely low power consumption
Direct replacement for BA15S base, single filament, Trade Number 97, Lamp Shape G6, 1156 Series also known as: 93, 3497, 1073, 1141, 1159, 1295, 7527 12814, 1003 (For Reference Only)
No UV or IR radiation, low heat
Base: BA15S, diameter 0.59” (15mm)
Size: Total length 1.45” (36.85mm, Max Diameter 0.748” (19mm)
Luminous flux: 119LM, Color temperature: 2800-3200K
Input: 12V, Built-in Circuit for 12V DC Voltage Input
(10 Pack) Dimmable and Waterproof IP65 Splash Proof G4
Perfect to replace 15W Halogen G4 Capsules, Automotive, RV, Boats, Spots & Pendants, Appliances, with a Silicon cover making them waterproof IP65, perfect for landscaping
Color: Warm White 3000K, 170 Lumens +-10%
No UV or IR radiation, low heat, highly efficient operation and low operating costs
Base: G4, enables fitting in any G4 luminaries
Input: 12V AC/DC, Power: 1.7W
Size: Φ12.6 x H28 mm (Φ0.5" x 1.10") (not including 10mm Pin Length)
Light source: 48 x 3014 LED, 360 degree Viewing Angle
An exceptionally long lamp life of up to 50,000 hours makes lamps ideal for inaccessible locations
